CRL Custom Oil Rubbed Bronze 1" Diameter Standoff Base - S0B1C0RB
This CRL Custom Standoff Base matches your Custom Cap, and is now available from the Manufacturing Division of CRL. As a result of customer requests for special lengths and finishes of Standoff Products, CRL provides custom fabrication of 1/2" (12 mm), 3/4" (19 mm), 1" (25 mm), 1-1/4" (31 mm), 1-1/2" (37.4 mm), 1-3/4" (44 mm) and 2" (51 mm) standoff base and cap assemblies.
Manufactured to Your Specification
Available in Many Finishes
Threaded Completely Through
Manufactured to Your Specification
Available in Many Finishes
Threaded Completely Through
Catalog Number: S0B1C0RB
Also Available in These Catalogs:
Color: Oil Rubbed Bronze
Diameter: 1" (25 mm)
Length: Custom
Ship Via: Can Ship UPS
Also Available in These Catalogs:
Color: Oil Rubbed Bronze
Diameter: 1" (25 mm)
Length: Custom
Ship Via: Can Ship UPS
CATALOG NUMBER DESCRIPTION COLOR
S0B1CBS CRL Custom 316 Brushed Stainless 1" Diameter Standoff Base
S0B1CBR CRL Custom Brass 1" Diameter Standoff Base
S0B1C0RB CRL Custom Oil Rubbed Bronze 1" Diameter Standoff Base
S0B1CPS CRL Custom 316 Polished Stainless 1" Diameter Standoff Base
S0B1CPT CRL Custom Painted 1" Diameter Standoff Base
S0B1CSB CRL Custom Satin Brass 1" Diameter Standoff Base
S0B1CSC CRL Custom Satin Chrome 1" Diameter Standoff Base
S0B1CBS CRL Custom 316 Brushed Stainless 1" Diameter Standoff Base
S0B1CBR CRL Custom Brass 1" Diameter Standoff Base
S0B1C0RB CRL Custom Oil Rubbed Bronze 1" Diameter Standoff Base
S0B1CPS CRL Custom 316 Polished Stainless 1" Diameter Standoff Base
S0B1CPT CRL Custom Painted 1" Diameter Standoff Base
S0B1CSB CRL Custom Satin Brass 1" Diameter Standoff Base
S0B1CSC CRL Custom Satin Chrome 1" Diameter Standoff Base
Custom Standoff Bases:
If the overall length of the base is 2" (51 mm) or less, the base will be drilled and tapped all the way through. If over 2" (51 mm), the base will be drilled and tapped at a depth of 1" (25.4 mm) on each end.
The thread sizes for Custom Caps and Bases are:
For less than 3/4" (19 mm) diameter, drill and tap for 10-24 screw thread.
For 3/4" (19 mm) to less than 1-1/4" (32 mm) diameter, drill and tap for 1/4"-20 screw thread.
For 1-1/4" (32 mm) to less than 1-1/2" (38 mm) diameter, drill and tap for 5/16"-18 screw thread.
For 1-1/2" (38 mm) diameter or greater, drill and tap for 3/8"-16 screw thread.
CRL Standoff Systems offer a complete range of mounting accessories that you can order in any quantity necessary for your project. For installation techniques or design assistance using CRL Standoffs, contact the CRL Technical Sales Department.
If the overall length of the base is 2" (51 mm) or less, the base will be drilled and tapped all the way through. If over 2" (51 mm), the base will be drilled and tapped at a depth of 1" (25.4 mm) on each end.
The thread sizes for Custom Caps and Bases are:
For less than 3/4" (19 mm) diameter, drill and tap for 10-24 screw thread.
For 3/4" (19 mm) to less than 1-1/4" (32 mm) diameter, drill and tap for 1/4"-20 screw thread.
For 1-1/4" (32 mm) to less than 1-1/2" (38 mm) diameter, drill and tap for 5/16"-18 screw thread.
For 1-1/2" (38 mm) diameter or greater, drill and tap for 3/8"-16 screw thread.
CRL Standoff Systems offer a complete range of mounting accessories that you can order in any quantity necessary for your project. For installation techniques or design assistance using CRL Standoffs, contact the CRL Technical Sales Department.
