CRL Brite Chrome Vernon 8260 Hydraulic All-Glass Door Hinge - No Hold Open - 31M8260CH

The Biloba Hinge represents the evolution and the synthesis between automatic mechanical hinges and hydraulic door closers. Designed for use on interior doors (not for Shower Doors) leading into the bathroom area, Biloba allows you to design a self-closing door without the need of a floor-mounted or overhead closing device. This gives you the advantage of being able to install an 'all-glass' door in an existing opening without the need for extensive retrofitting of hardware into the floor or overhead.
Properly mounted, two Biloba Hinges will support a 3/8" to 1/2" (10 to 12 mm) thick glass door up to 39" (1 m) in width and weighing up to 220 lbs. (100 kg). (Do not use more than two hinges.) A control valve lets you adjust the hinge to the desired closing speed. And Biloba is ambidextrous, with positive stop at 0 degrees, giving you even more design freedom.
The Biloba Hinge features an aluminum body in distinct configurations for Wall Mount and Glass-to-Glass applications. Biloba has been subject to strict testing (over 1 million cycles), assuring long lasting service.
SPECIFICATIONS:
Glass Thickness Range: 3/8" to 1/2" (10 to 12 mm)
Construction: Aluminum
Hinge Swings: 90 Degrees One Way
Closing Type: Automatic Closing From 0 to 80 Degrees
Cut-Out Required
Includes: Snap-In Molded Gaskets for 3/8" (10 mm) and 1/2" (12 mm) Glass; Hex Screws Maximum Capacities Using Two Hinges: Door Width: 39" (1 m); Door Weight: 220 lbs. (100 kg)
