CRL Oil Rubbed Bronze 92" Floor-to-Ceiling Vertical Post System - VPK920RB
CRL offers two styles of our Frameless Vertical Post System. They are used to stabilize fixed panels of glass not reaching the ceiling, and provide an excellent alternative to customers not wanting to use the more traditional horizontal Header Systems that run across the entire width of the enclosure. An especially attractive look is when patterned glass with decorative, rippled top edges is used, since a Header System cannot be applied as a crown to the glass.
Stock or Custom Kits Allow User to Stabilize Fixed Panels of Glass Not Going to Ceiling
Excellent Alternative to Traditional Horizontal Header Systems
Four Popular Stock Finishes For 5/16", 3/8", and 1/2" (8, 10, and 12 mm) Glass
Glass Fabrication Required for Tube Adaptors/End Caps [3/4" (19 mm) Holes]
Custom Kits Available in Various Finishes, Post Configurations, and With Dome or Ball Style Glue-In End Caps (Two-Point System Only)
Use Monolithic Tempered Glass
Stock or Custom Kits Allow User to Stabilize Fixed Panels of Glass Not Going to Ceiling
Excellent Alternative to Traditional Horizontal Header Systems
Four Popular Stock Finishes For 5/16", 3/8", and 1/2" (8, 10, and 12 mm) Glass
Glass Fabrication Required for Tube Adaptors/End Caps [3/4" (19 mm) Holes]
Custom Kits Available in Various Finishes, Post Configurations, and With Dome or Ball Style Glue-In End Caps (Two-Point System Only)
Use Monolithic Tempered Glass
Catalog Number: VPK920RB
Also Available in These Catalogs:
SD16 Frameless Shower Door Hardware 2015, PAGE 206S
CRL23R Frameless Shower Door and Mirror Hardware, PAGE 316J
CRL93A Shower Door, PAGE SD120
Color: Oil Rubbed Bronze
Ship Via: UPS Oversize Rate
Minimum Order: 1 Each
Also Available in These Catalogs:
SD16 Frameless Shower Door Hardware 2015, PAGE 206S
CRL23R Frameless Shower Door and Mirror Hardware, PAGE 316J
CRL93A Shower Door, PAGE SD120
Color: Oil Rubbed Bronze
Ship Via: UPS Oversize Rate
Minimum Order: 1 Each
CATALOG NUMBER DESCRIPTION COLOR
VPK920RB CRL Oil Rubbed Bronze 92" Floor-to-Ceiling Vertical Post System
VPK92BN CRL Brushed Stainless Steel 92" Floor-to-Ceiling Vertical Post System
VPK92CH CRL Polished Stainless Steel 92" Floor-to-Ceiling Vertical Post System
VPK920RB CRL Oil Rubbed Bronze 92" Floor-to-Ceiling Vertical Post System
VPK92BN CRL Brushed Stainless Steel 92" Floor-to-Ceiling Vertical Post System
VPK92CH CRL Polished Stainless Steel 92" Floor-to-Ceiling Vertical Post System
Two stock systems are offered the Floor-to-Ceiling Mount System and the Two-Point Ceiling Mount System. Stock Systems are prepared for behind-the-glass installation. Custom Systems and finishes are available by simply submitting a drawing to our Frameless Shower Door Technical Department. Tube Adaptors/End Caps require 3/4" (19 mm) holes in glass. Complete mounting details and installation instructions are available.
STOCK KIT INCLUDES:
1 Each - 92" (2.3 m) length of 2" (51 mm) diameter Round Tubing with welded Bottom Flange and two Rivet Nuts
2 Each - Tube Adaptors with 1-1/2" (38 mm) diameter End Caps (with Threaded Stud)
1 Each Removable Top Flange with Set Screw
NOTE: Stock Kit is prepared for one degree floor slope to the inside of the shower. Shimming is required if floor is not a one degree slope to the inside of the shower, or a Custom Kit may be ordered instead.
STOCK KIT INCLUDES:
1 Each - 92" (2.3 m) length of 2" (51 mm) diameter Round Tubing with welded Bottom Flange and two Rivet Nuts
2 Each - Tube Adaptors with 1-1/2" (38 mm) diameter End Caps (with Threaded Stud)
1 Each Removable Top Flange with Set Screw
NOTE: Stock Kit is prepared for one degree floor slope to the inside of the shower. Shimming is required if floor is not a one degree slope to the inside of the shower, or a Custom Kit may be ordered instead.
