CRL Brushed Nickel Adjustable "Sleeve Over" Glass Clamp - S0GC91BN
Finish: BRUSHED NICKEL
$31.64
CRL Sleeve Over Glass Clamps are designed to provide a mechanical fastener to cover the shear forces placed on the glass panels. No special fabrication of the glass is required. Can also be used to secure the glass panels in position while the applied silicone sealant in the joint cures (the silicone sealant glues the glass panels together, prevents water leakage, and provides the pull strength to keep the panels from separating). Clamps are secured in place by nylon tipped Allen set screws.
For 5/16" to 1/2" (8 to 12 mm) Thick Glass
Use Monolithic Tempered Glass
Adjustable from 90 to 180 Degrees
Solid Brass
Assists with Shear Forces
Holds Glass Panels in Position While Sealant Cures
For 5/16" to 1/2" (8 to 12 mm) Thick Glass
Use Monolithic Tempered Glass
Adjustable from 90 to 180 Degrees
Solid Brass
Assists with Shear Forces
Holds Glass Panels in Position While Sealant Cures
Catalog Number: S0GC91BN
Also Available in These Catalogs:
SD16 Frameless Shower Door Hardware 2015, PAGE 195S
CRL53R Glass & Glazing Catalog, PAGE 279G
CRL23R Frameless Shower Door and Mirror Hardware, PAGE 295J
CRL93A Shower Door, PAGE SD103
Color: Brushed Nickel
Ship Via: Can Ship UPS
Shipping Weight: 8 oz (227g)
Minimum Order: 1 Each
Also Available in These Catalogs:
SD16 Frameless Shower Door Hardware 2015, PAGE 195S
CRL53R Glass & Glazing Catalog, PAGE 279G
CRL23R Frameless Shower Door and Mirror Hardware, PAGE 295J
CRL93A Shower Door, PAGE SD103
Color: Brushed Nickel
Ship Via: Can Ship UPS
Shipping Weight: 8 oz (227g)
Minimum Order: 1 Each
CATALOG NUMBER DESCRIPTION COLOR
S0GC91CH CRL Chrome Adjustable "Sleeve Over" Glass Clamp
S0GC91ULBR CRL Unlacquered Brass Adjustable "Sleeve Over" Glass Clamp
S0GC91BR CRL Brass Adjustable "Sleeve Over" Glass Clamp
S0GC910RB CRL Oil Rubbed Bronze Adjustable "Sleeve Over" Glass Clamp
S0GC91BBRZ CRL Brushed Bronze Adjustable "Sleeve Over" Glass Clamp
S0GC91BN CRL Brushed Nickel Adjustable "Sleeve Over" Glass Clamp
S0GC91BSC CRL Brushed Satin Chrome Adjustable "Sleeve Over" Glass Clamp
S0GC91MBL CRL Matte Black Adjustable "Sleeve Over" Glass Clamp
S0GC91PN CRL Polished Nickel Adjustable "Sleeve Over" Glass Clamp
S0GC91SC CRL Satin Chrome Adjustable "Sleeve Over" Glass Clamp
S0GC91CH CRL Chrome Adjustable "Sleeve Over" Glass Clamp
S0GC91ULBR CRL Unlacquered Brass Adjustable "Sleeve Over" Glass Clamp
S0GC91BR CRL Brass Adjustable "Sleeve Over" Glass Clamp
S0GC910RB CRL Oil Rubbed Bronze Adjustable "Sleeve Over" Glass Clamp
S0GC91BBRZ CRL Brushed Bronze Adjustable "Sleeve Over" Glass Clamp
S0GC91BN CRL Brushed Nickel Adjustable "Sleeve Over" Glass Clamp
S0GC91BSC CRL Brushed Satin Chrome Adjustable "Sleeve Over" Glass Clamp
S0GC91MBL CRL Matte Black Adjustable "Sleeve Over" Glass Clamp
S0GC91PN CRL Polished Nickel Adjustable "Sleeve Over" Glass Clamp
S0GC91SC CRL Satin Chrome Adjustable "Sleeve Over" Glass Clamp
SPECIFICATIONS:
Material: Solid Brass
Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
No Glass Fabrication Required (Clamps tighten using nylon tipped Allen screws).
Includes: Gaskets
NOTE: These Clamps are not designed to take the place of Headers or a Support Bar. Contact CRL Frameless Shower Technical Sales Department for more details. Can be used on both square cut or mitered panels.
Material: Solid Brass
Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
No Glass Fabrication Required (Clamps tighten using nylon tipped Allen screws).
Includes: Gaskets
NOTE: These Clamps are not designed to take the place of Headers or a Support Bar. Contact CRL Frameless Shower Technical Sales Department for more details. Can be used on both square cut or mitered panels.
