CRL Dark Bronze 36" x 96" Jackson® 1275 Push Pad Surface Vertical Rod Panic Exit Device - 31127538313
Catalog Number: 31127538313
Also Available in These Catalogs:
CRL93A Architectural Hardware, PAGE CH075
Color: Dark Bronze
Type: 96" Surface Vertical Rod
Handing: Non-Handed
Ship Via: Can Ship UPS
Shipping Weight: 8 lb (3.63kg)
Also Available in These Catalogs:
CRL93A Architectural Hardware, PAGE CH075
Color: Dark Bronze
Type: 96" Surface Vertical Rod
Handing: Non-Handed
Ship Via: Can Ship UPS
Shipping Weight: 8 lb (3.63kg)
CATALOG NUMBER DESCRIPTION COLOR
31127538313 CRL Dark Bronze 36" x 96" Jackson 1275 Push Pad Surface Vertical Rod Panic Exit Device
31127538313 CRL Dark Bronze 36" x 96" Jackson 1275 Push Pad Surface Vertical Rod Panic Exit Device
The 1200 Series touch pad with "Soft-Touch" insert requires slight pressure anywhere on the bar insert for instant release of the locking mechanism. Overall projection is only 2-7/8" (73 mm) from the door surface, and mounting hardware is concealed. Active outside trim and other panic accessories are available.
SPECIFICATIONS:
1275 Surface Vertical Rod Device
Stocked in Both 36" and 48" (914 mm and 1.22 m)
Standard Door Heights 84" (2.13 m) and 96" (2.44 m) Field Sizeable
MATERIALS:
Base and Push-Pad: Extruded Aluminum
Mechanical Components: Stainless and Hardened, Plated Steel
Latch and Strikes: Sintered Steel
Metal End Caps
SPECIFICATIONS:
1275 Surface Vertical Rod Device
Stocked in Both 36" and 48" (914 mm and 1.22 m)
Standard Door Heights 84" (2.13 m) and 96" (2.44 m) Field Sizeable
MATERIALS:
Base and Push-Pad: Extruded Aluminum
Mechanical Components: Stainless and Hardened, Plated Steel
Latch and Strikes: Sintered Steel
Metal End Caps
If this item is ordered with the "Cylinder Dogging" feature, the manufacturer does not provide the cylinder, only the prep. It requires a 1-1/8" (28.6 mm) length mortise cylinder, which is not stocked by CRL, but can be special ordered.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting Glass Experts customer service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting Glass Experts customer service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
