CRL Brushed Stainless Z-Series Flat Surface Mount Square Type Glass Clamps for 13/16" Glass - Z91316BS

CRL Brushed Stainless Z-Series Flat Surface Mount Square Type Glass Clamps for 13/16" (20.6 mm) Tempered Laminated Glass.
For Use with Square Tubing or Other Flat Surfaces
316 Alloy Stainless Steel
For 13/16" (20.6 mm) Glass (Flat Surface Mounting)
Use Tempered Laminated Glass
Catalog Number: Z91316BS
Also Available in These Catalogs:
This Item is Not Yet Shown in Any Printed Catalog.
Color: Brushed Stainless
Width: 2-1/8" (54 mm)
Height: 2-9/16" (65 mm)
Ship Via: Can Ship UPS
Shipping Weight: 1 lb (454g)
Minimum Order: 1 Each
CATALOG NUMBER DESCRIPTION COLOR
Z91316BS CRL Brushed Stainless Z-Series Flat Surface Mount Square Type Glass Clamps for 13/16" Glass
SPECIFICATIONS:
Glass Thickness: 13/16" (20.6 mm)
Base Design: Flat
For Use With: Square Tubing or Other Flat Surfaces
Material: 316 Alloy Stainless Steel
Glass Fabrication: One 7/8" (22 mm) diameter finger notch is required. The included steel pin must be used for 13/16" (20.6 mm) Laminated Glass applications.
Includes: Rubber Gaskets and Steel Pin
