CRL Chrome Z-Series Square Type Radius Base Zinc Clamps for 3/8" and 1/2" Glass with Repositionable Plate - ZL610CH

Finish: CHROME
$23.16
Quantity

This CRL Z-Series Square Type Radius Base Glass Clamp with Repositionable Plate is designed to be used on glass thickness of 3/8" (10 mm) and 1/2" (12.7 mm). Constructed from zinc, the clamps are the perfect solution for partitions, railings, windbreaks and countless other projects.
Repositionable Plate for Use at Right or Left Corner of Glass
For Use with 2" (51 mm) Diameter Round Tubing
For 3/8" or 1/2" (10 or 12 mm) Glass
Radius Surface Mounting
Use Monolithic Tempered Glass
Catalog Number: ZL610CH
Also Available in These Catalogs:
HR18 Architectural Railing Systems 2018, PAGE 308B
SC18 Standoff and Clamp Hardware, PAGE 48SC
CRL93A Architectural Railings, PAGE HR104
Color: Chrome
Width: 2-1/8" (54 mm)
Height: 2-3/8" (60 mm)
Ship Via: Can Ship UPS
Minimum Order: 1 Each
CATALOG NUMBER DESCRIPTION COLOR
ZL610BN CRL Brushed Nickel Z-Series Square Type Radius Base Zinc Clamps for 3/8" and 1/2" Glass with Repositionable Plate
ZL610CH CRL Chrome Z-Series Square Type Radius Base Zinc Clamps for 3/8" and 1/2" Glass with Repositionable Plate
ZL610SC CRL Satin Chrome Z-Series Square Type Radius Base Zinc Clamps for 3/8" and 1/2" Glass with Repositionable Plate
ZL610W CRL White Z-Series Square Type Radius Base Zinc Clamps for 3/8" and 1/2" Glass with Repositionable Plate
ZL710BS CRL Brushed Stainless Steel Z-Series Square Type Radius Base Zinc Clamps for 3/8" and 1/2" Glass with Repositionable Plate
ZL710PS CRL Polished Stainless Steel Z-Series Square Type Radius Base Zinc Clamps for 3/8" and 1/2" Glass with Repositionable Plate
SPECIFICATIONS:
Glass Thickness: 3/8" or 1/2" (10 or 12 mm).
Base Design: Radius.
For Use With: 2" (51 mm) Diameter Round Tubing.
Material: Zinc Constructed
Glass Fabrication:
For 3/8" (10 mm) Thick Glass: 1/2" (12 mm) diameter hole required if using provided steel pin for glass support.
For 1/2" (12 mm) Thick Glass: 9/16" (14 mm) diameter hole required if using provided steel pin for glass support.
Includes: Repositionable Plate for Use at Right or Left Corner of Glass.
