DORMAKABA® Brushed Stainless Bottom Door Patch Fitting with Bottom Insert For 3/4" Glass - PT1034BS

Finish: BRUSHED STAINLESS
$269.12
Quantity

DORMAKABA® Bottom Patch Fittings are used with our bottom door pivots or floor closers. It fits in the lower corner of the glass panel, and requires a hole and cut-out in the glass. Available in brushed or polished stainless steel finishes.
2-3/4" (70 mm) Pivot Setback
For 3/4" (19 mm) Glass
Use Monolithic Tempered Glass
Catalog Number: PT1034BS
Also Available in These Catalogs:
AH18 Architectural Hardware Catalog 2018, PAGE 226Z
CRL93A Architectural Hardware, PAGE CH136
Color: Brushed Stainless
Ship Via: Can Ship UPS
Minimum Order: 1 Each
CATALOG NUMBER DESCRIPTION COLOR
PT1034BS DORMAKABA Brushed Stainless Bottom Door Patch Fitting with Bottom Insert For 3/4" Glass
PT1034PS DORMAKABA Polished Stainless Bottom Door Patch Fitting with Bottom Insert For 3/4" Glass
The following guidelines are to be used when making a door using this hardware:
Maximum Height: 102" (2.59 m)
Maximum Weight: 194 Lbs. (88 kg)
Maximum Width: 42" (1.09 m)
If the door exceeds any of these limitations, full door rails should be used.
GLASS FABRICATION REQUIRED:
One 3/4" (19 mm) Diameter
Hole and Corner Notch
COMES WITH:
Template and Instructions
